Celtron SEB-2.5 t Single Ended Beam Load Cell, OIML C3

MSRP: $228.00
$216.60
(Save $11.40)
Part #:
69319
Availability:
Typically ships in 1-2 days

Celtron SEB-2.5 t Single Ended Beam Load Cell

Features

  • 2.5 ton capacity rating
  • Alloy steel construction, nickel plated
  • IP 67 rating
  • 3 mV/V output
  • Load cell cable length 20 ft
  • Safe overload up to 150% capacity

Common Applications

  • OEM
  • Low profile scales
  • Floor scales
  • Tank/Hopper scales
1 year limited manufacturer's warranty
Manufacturer:
Celtron
Model:
SEB-2.5 t
Approvals:
cFM, OIML C3
Capacity Rating:
2.5 ton
Safe Overload:
150% capacity
Height:
1.25"
Length:
5.12"
Width:
1.5"
Threading:
M12 x 1.75
Construction / Finish:
High-alloy steel, nickel plated
Cable Color Code:
Red = + Excitation, Black = - Excitation, Green = + Signal, White = - Signal, Bare = Shield
Rated Excitation:
5-10 VAC/DC (maximum of 15 V)
Full Scale Output:
3 mV/V
Output Resistance:
350 (+/- 3) ohms
Input Resistance:
385 (+/- 5) ohms
Operating Temperature Range:
-40‚° F to 150‚° F / -40‚°C to 65‚°C
Seal Type:
IP67 Environmentally Sealed
Combined Error:
0.025%
Insulation Resistance:
5000 megohms
Cable Length:
20 ft
Cable Diameter:
0.200 polyurethane jacket
