Rice Lake RL20000I-500 500 lb S-Beam Load Cell, NTEP

MSRP: $290.00
$275.50
(Save $14.50)
Part #:
21436
Availability:
Typically ships in 1-2 days

Rice Lake RL20000I-500 500 lb S-Beam Load Cell, NTEP

Rice Lake RL20000 S-Beam load cells are best suited for use in hanging scale applications such as hoppers or tanks. The RL20000 load cell is constructed of nickel plated alloy steel and has a 20 ft long load cell cable. They are environmentally sealed and have an IP 67 rating. RL20000 load cells can be purchased in a wide variety of capacity ratings from 25 lbs up to 20,000 lbs.

RL20000 load cells are used in the Rice Lake ITCM (Isolated Tension Cell Module) kit.

Features

  • 500 lb capacity rating
  • Alloy steel construction, nickel plated
  • IP 67 rating
  • 3 mV/V output
  • Load cell cable length 20 ft
  • 2 year limited manufacturer's warranty
  • NTEP Approved
  • Safe overload up to 150% capacity
2 year limited manufacturer's warranty
Manufacturer:
Rice Lake Weighing Systems
Model:
RL20000I-500
Part Number:
21436
Certification:
NTEP Certified 1:5000 III / 1:10,000 IIIL
Other Approvals:
cFM, CE
Capacity Rating:
500 lb / 226.8 kg
Safe Overload:
150% capacity
Rated Excitation:
5-10 VDC (maximum of 15 V)
Height:
2.5"
Width:
2"
Depth:
0.75"
Hole Threading:
1/2-20 UNF-2B
Construction / Finish:
High-alloy steel, nickel plated
Cable Color Code:
Red = + Excitation, Black = - Excitation, Green = + Signal, White = - Signal
Full Scale Output:
3.0 mV/V
Output Resistance:
350 (+/- 3) ohms
Input Resistance:
385 (+/- 5) ohms
Compensated Temperature Range:
14° F to 104° F / -10°C to 40°C
Operating Temperature Range:
-40° F to 150° F / -40°C to 65°C
Seal Type:
IP67 Environmentally Sealed
Combined Error:
0.02%
Insulation Resistance:
5000 megohms
Cable Length:
20 ft
Cable Diameter:
0.200 polyurethane jacket
Interchangeable Products:
Artech 20210 (1-14 UNF)
