Sensortronics 60050-15K 15,000 lb Stainless Steel S-Beam Load Cell

MSRP: $689.00
$654.55
(Save $34.45)
Part #:
17087
Availability:
Typically ships in 1-2 days

Sensortronics 60050-15K 15,000 lb Stainless Steel S-Beam Load Cell

Features

  • 15,000 lb / 6803.9 kg capacity rating
  • Stainless steel constructed
  • Environmentally sealed IP67
  • 3 mV/V output
  • Load cell cable length 20 ft
  • 1 year limited warranty
  • Safe overload up to 150% capacity

Common Applications

  • OEM
  • Suspended/hanging scales
  • Tension scales

Interchange

  • VPG Celtron STC SS
1 year limited manufacturer's warranty
Manufacturer:
Sensortonics
Model:
60050-15K
Approvals:
FM
Capacity Rating:
15,000 lb / 6803.9 kg
Safe Overload:
150% capacity
Length:
4"
Height:
5.5"
Width:
1.5"
Hole Threading:
1-14UNF
Construction / Finish:
Stainless steel
Cable Color Code:
Red = + Excitation, Black = - Excitation, Green = + Signal, White = - Signal
Rated Excitation:
5-10 VDC (maximum of 15 V)
Full Scale Output:
3 mV/V nominal
Output Resistance:
349-355 ohms
Input Resistance:
343-450 ohms
Insulation Resistance:
5000 megohms
Compensated Temperature Range:
14‚°F to 104‚°F (-10‚°C to 40‚°C)
Operating Temperature Range:
-40‚° F to 150‚° F / -40‚°C to 65‚°C
Seal Type:
Environmentally sealed IP67
Nonlinearity:
0.03 % full scale
Hysteresis:
0.02 % full scale
Cable Length:
20 ft
Cable Diameter:
0.200 polyurethane jacket
Weigh Module Available:
ITCM Isolated Tension Cell Mount
