Totalcomp TB743-10K Single Ended Beam Load Cell, 10,000 lb

MSRP: $1,111.11
$999.99
(Save $111.12)
Part #:
2913
Availability:
Typically ships in 1-2 days

Totalcomp TB743 series single ended beam load cells are commonly used in medium to heavy capacity weighing applications. Totalcomp TB743 series shear beam load cells include a 20 ft load cell cable, are constructed of stainless steel, and are hermetically sealed with an IP68 rating.

Features

  • Stainless steel
  • Washdown safe
  • 2 mV/V output
  • IP68 rating, hermetically sealed
  • Load cell cable length 20 ft

Interchange

  • Toledo 743 Flexmount

Documentation

Totalcomp TB743 Datasheet

1 year limited manufacturer's warranty
Capacity:
10,000 lb
Construction:
Stainless steel
Cable Color Code:
Green = + Excitation, Black = - Excitation, White = + Signal, Red = - Signal, Yellow = Shield
Rated Excitation:
10 VDC (maximum of 15 V)
Full Scale Output:
2 mV/V
Input Resistance:
350 ohms
Output Resistance:
350 ohms
IP Rating:
IP68
Seal Type:
Hermetically sealed
Nonlinearity:
0.05 % full scale
Hysteresis:
0.05 % full scale
Zero Balance:
1 % full scale
Ultimate Overload:
150 % full scale
Safe Temperature Range:
-10C to 40C
Operating Temperature Range:
-10C to 40C
Cable Length:
20 ft
Manufacturer:
Totalcomp
Model:
TB743-10K
Part Number:
2913
