Totalcomp TP-MK4D-10-SS Single Point Load Cell, 10 lb

MSRP: $557.87
$502.08
(Save $55.79)
Part #:
2428
Availability:
Typically ships in 1-2 days

Totalcomp TP-MK4D-SS series single point load cells are constructed of stainless steel and feature an IP67 protection rating. Totalcomp TP-MK4D-SS series load cells include a 10 ft cable and safe overload rating of up to 300% capacity.

Features

  • Stainless steel construction
  • 2 mV/V output
  • IP67 rating
  • Load cell cable length 10 ft
  • Safe overload up to 300% capacity
  • Overload stops for both compression and tension loads

Interchange

  • NCI Model MK 4

Documentation

Totalcomp TP-MK4D Datasheet

1 year limited manufacturer's warranty
Capacity:
10 lb
Construction:
Stainless steel
Cable Color Code:
Red = + Excitation, Black = - Excitation, White = + Signal, Green = - Signal
Rated Excitation:
10 VDC (maximum of 15 V)
Full Scale Output:
2 mV/V
Input Resistance:
350 ohms
Output Resistance:
350 ohms
IP Rating:
IP67
Seal Type:
Environmentally sealed
Total Error:
0.3 % full scale
Safe Overload:
300 % full scale
Safe Temperature Range:
14C to 122C
Cable Length:
10 ft
Manufacturer:
Totalcomp
Model:
TP-MK4D-10-SS
Part Number:
2428
