Totalcomp TSB-2K Single Ended Beam Load Cell, 2000 lb, NTEP

MSRP: $308.28
$277.45
(Save $30.83)
Part #:
2252
Availability:
Typically ships in 1-2 days

Totalcomp TSB series single ended beam load cells are commonly used in medium to heavy capacity weighing applications. Totalcomp TSB series shear beam load cells have a threaded hole, 20 ft load cell cable, and are constructed of alloy steel with nickel plating. NTEP approved models range from 1000 lb to 10,000 lb capacities.

Features

  • Alloy steel with nickel plated construction
  • Threaded hole
  • 3 mV/V output
  • IP67 rating
  • Load cell cable length 20 ft
  • Safe overload up to 150% capacity

Interchange

  • Sensortronics 65023
  • Revere 5123

Documentation

Totalcomp TSB Single Ended Beam Data Sheet

1 year limited manufacturer's warranty
Capacity:
2000 lb
NTEP:
Yes
Class:
III/IIIL
NTEP CC:
93-123
Hole Threading:
1/2-20 UNF
Construction:
Alloy steel
Cable Color Code:
Red = + Excitation, Black = - Excitation, Green = + Signal, White = - Signal, Bare = Shield
Rated Excitation:
10 VDC (maximum of 15 V)
Full Scale Output:
3 mV/V
Input Resistance:
350 ohms
Output Resistance:
350 ohms
IP Rating:
IP67
Nonlinearity:
0.03 % full scale
Hysteresis:
0.05 % full scale
Zero Balance:
+/- 1.00% full scale
Safe Overload:
150 % full scale
Ultimate Overload:
300 % full scale
Safe Temperature Range:
-10C to 40C
Operating Temperature Range:
-16C to 65C
Cable Length:
20 ft
Manufacturer:
Totalcomp
Model:
TSB-2K
Part Number:
2252
