Totalcomp TSB-5K-SE-SS Single Ended Beam Load Cell, 5000 lb, Small Envelope, NTEP

MSRP: $339.63
$305.67
(Save $33.96)
Part #:
2266
Availability:
Typically ships in 1-2 days

Totalcomp TSB-SS series single ended beam load cells are commonly used in medium to heavy capacity weighing applications. Totalcomp TSB-SS series shear beam load cells have a threaded hole, 20 ft load cell cable, and are constructed of stainless steel. NTEP approved models are from 1000 lb to 10,000 lb capacities.

Features

  • Small envelope
  • Stainless steel
  • Threaded hole
  • 3 mV/V output
  • IP67 rating
  • Load cell cable length 20 ft
  • Safe overload up to 150% capacity

Interchange

  • Sensortronics 65023
  • Revere 5123

Documentation

Totalcomp TSB-SS Single Ended Beam Data Sheet

1 year limited manufacturer's warranty
Capacity:
5000 lb
NTEP:
Yes
Class:
III/IIIL
NTEP CC:
93-123
Hole Threading:
1/2-20 UNF
Construction:
Stainless steel
Cable Color Code:
Red = + Excitation, Black = - Excitation, Green = + Signal, White = - Signal, Bare = Shield
Rated Excitation:
10 VDC (maximum of 15 V)
Full Scale Output:
3 mV/V
Input Resistance:
350 ohms
Output Resistance:
350 ohms
IP Rating:
IP67
Nonlinearity:
0.03 % full scale
Hysteresis:
0.05 % full scale
Zero Balance:
+/- 1.00% full scale
Safe Overload:
150 % full scale
Ultimate Overload:
300 % full scale
Safe Temperature Range:
-10C to 40C
Operating Temperature Range:
-16C to 65C
Cable Length:
20 ft
Manufacturer:
Totalcomp
Model:
TSB-5K-SE-SS
Part Number:
2266
