Features
- Material: Stainless steel
- Rated Capacity: 500kg
- NTEP certified, Class III
- Full Scale Output: 2mV/V ± 0.25%
- Safe Overload: 150%
- Breaking Overload: 300%
- IP Rating: IP68
Documentation
1 year manufacturer's limited warranty
- Capacity:
- 500kg
- Approvals:
- CE, RoHS, OIML, NTEP, Ex Atex, FM Approved
- NTEP:
- Yes
- Class:
- III
- Safe Overload:
- 150% capacity
- Construction:
- Stainless steel
- Cable Color Code:
- Red = + Excitation, Black = - Excitation, Green= + Signal, White = - Signal, Bare = Shield
- Rated Excitation:
- 10 V (maximum of 15 V)
- Full Scale Output:
- 2.0 mV/V ±.25%
- Output Resistance:
- 960 (± 50) ohms
- Input Resistance:
- 1100 (± 50) ohms
- Compensated Temperature Range:
- 14°F to 122°F/-10°C to 50°C
- Seal Type:
- Welded sealed
- IP Rating:
- IP68
- Cable Length:
- 3 m
- Manufacturer:
- Anyload
- Model:
- 651KS55UN-500kg
