Features
- Stainless steel construction
- IP 67 rating environmentally sealed
- 2.00 mV/V output
- Load cell cable length 50 ft
- Safe overload up to 150% capacity
Interchangeable Products
- Toledo 04966 Series
- Toledo 04967 Series
- Toledo 04968 Series
- Totalcomp T496
Documentation
1 year limited manufacturer's warranty
- Capacity:
- 5,000 lb
- Repeatability:
- +/- 0.01% full scale
- Rated Output:
- 2.00 mV/V +/- 0.25%
- Rated Excitation:
- 10V AC/DC (15V max)
- Safe Overload:
- 150% full scale
- Output Resistance:
- 240 +/- 5 ohms
- Input Resistance:
- 260 +/- 10 ohms
- Insulation Resistance:
- 5000 megohms
- Operating Temperature Range:
- -10°C to 40°C
- Construction:
- Stainless steel
- Seal Type:
- Hermetically
- IP Rating:
- IP67
- Approvals:
- FM
- Nonlinearity:
- +/- 0.05% full scale
- Hysteresis:
- +/- 0.03% full scale
- Creep (30) Minutes:
- +/- 0.03% full scale
- Zero Balance:
- +/- 1.00% full scale
- Cable Length:
- 50 ft
- Cable Color Code:
- Green = + Excitation, Black = - Excitation, White = + Signal, Red = - Signal
- Manufacturer:
- Coti Global Sensors
- Part Number:
- CG-CP22 5K
