Features
- Stainless steel construction
- NTEP, OIML, and FM approved
- IP 68 rating hermetically sealed
- 2.00 mV/V output
- Load cell cable length 16.4 ft
- Safe overload up to 150% capacity
Documentation
1 year limited manufacturer's warranty
- Capacity:
- 4,000 lb
- Repeatability:
- +/- 0.01% full scale
- Rated Output:
- 2.00 mV/V +/- 0.5%
- Rated Excitation:
- 10V AC/DC (30V max)
- Safe Overload:
- 150% full scale
- Output Resistance:
- 1025+/- 25 ohms
- Input Resistance:
- 1110 +/- 50 ohms
- Insulation Resistance:
- 5000 megohms
- Operating Temperature Range:
- -10°C to 40°C
- Construction:
- Stainless steel
- Seal Type:
- Hermetically
- IP Rating:
- IP68
- Approvals:
- FM, NTEP, OIML
- Nonlinearity:
- +/- 0.02% full scale
- Hysteresis:
- +/- 0.02% full scale
- Creep (30) Minutes:
- +/- 0.03% full scale
- Zero Balance:
- +/- 2.00% full scale
- Cable Length:
- 16.4 ft
- Cable Color Code:
- Pink = + Excitation, Gray = - Excitation, Brown = + Signal, White = - Signal
- Manufacturer:
- Coti Global Sensors
- Part Number:
- CG-RLC 2t
