Features
- Stainless stell single-ended beam load cell
- NTEP-approved
- 5000 lb capacity rating
- IP 67 rated
- 2 mV/V output
- Load cell cable length 20 ft
Interchangeable Products
- Avery Weigh-Tronix Weigh Bar
- Rice Lake RL75000SS
Documentation
2 year limited manufacturer's warranty
- Capacity:
- 5,000 lb
- Safe Overload:
- 150% full scale
- Rated Excitation:
- 5 to 10 VDC
- Full Scale Output:
- 2.0 (±0.1%) mV/V
- Output Resistance:
- 350 (±3) ohm
- Insulation Resistance:
- 5,000 megohm
- Construction:
- Stainless steel
- Seal Type:
- Environmentally
- IP Rating:
- IP67
- Cable:
- 20 ft, Polyurethane jacket
- Cable Color Code:
- Green = + Excitation, Black = - Excitation, White = + Signal, Red = - Signal,
- NTEP:
- Class III
- Compensated Temperature Range:
- 14 °F to 104 °F
- Operating Temperature Range:
- 0 °F to 150 °F
- Manufacturer:
- Rice Lake Weighing Systems
- Model:
- RL32011WB-L
- Part Number:
- 119790
