Features
- Stainless steel single-ended beam load cell
- NTEP-approved
- 60,000 lb capacity rating
- IP 69 rated
- 2 mV/V output
- Load cell cable length 15 ft
2 year limited manufacturer's warranty
- Capacity:
- 60,000 lb
- Safe Overload:
- 200% full scale
- Rated Excitation:
- 5 to 10 VDC (15 V max)
- Full Scale Output:
- 2.0 mV/V
- Output Resistance:
- 1,000 (±2) ohm
- Input Resistance:
- 1,150 (±50) ohm
- Construction:
- Stainless steel
- Seal Type:
- Hermetically
- IP Rating:
- IP69
- Cable:
- 15 ft, Stainless steel overbraid cable
- Cable Color Code:
- Green = + Excitation, Black = - Excitation, White = + Signal, Red = - Signal,
- NTEP:
- Class IIIL
- Compensated Temperature Range:
- 14 °F to 104 °F
- Operating Temperature Range:
- 0 °F to 150 °F
- Manufacturer:
- Rice Lake Weighing Systems
- Model:
- RL70510
- Part Number:
- 169363
